Spider 18.90 PRO Hybrid
1/1
TECHNICAL DATA
Max. working Height
Max. basket floor Height
Max. Lateral outreach
Rotation angle
Basket dimensions
Max. working load
Length stowed position
Length stowed (basket det.)
Min. stowed width
Min. stowed height
Outriggers footprint
Max. gradeability
Max. lateral gradeability
Total weight
Ground tracks load
Max. pressure (Working condition)
17.60m
15.60m
9.20m
360 Deg.
1.30 x 0.70m
200Kg (2 person)
5.00m
4.36m
0.78m
1.95m
3.00 x 3.63m
16 Deg. (29%)
17 Deg. (31%)
2,650Kg (ED)
3.69KN/m2
2.25KN/m2
Some specification may differ due to individual machine options. Please confirm exact specification against detailed technical data sheet provided at time of booking your Spider Lift Hire.
